Status

Navigation: Configuration > Packet filter > Status

The Status tab provides a real-time graphical view of packet filter throughput. It displays the current data rate for individual filter chains, allowing operators to monitor network traffic volumes and verify that the configured Packet filter rules are processing traffic as expected. This read-only view is useful for diagnostics and for identifying unexpected traffic patterns.

Status display

The page shows a bar chart with the vertical axis scaled in MBit/s (from 0 to 100 MBit/s), representing the current throughput of the selected filter chain.

Select Chain

Use this dropdown to select the packet filter chain to display. Each chain corresponds to a configured rule set or a built-in system chain. Select a chain to view its current throughput in the chart.

Compare with

Use this dropdown to select a second filter chain for comparison. When a second chain is selected, its throughput is displayed alongside the first, enabling a side-by-side comparison of traffic volumes between different rule sets or interfaces.

Reload

Click the Reload button at the bottom of the page to refresh the chart with the latest throughput data.
